V-plows (Butterfly Plows)

Heavy-duty V-shaped snow plows for tractors and loaders, designed for professional snow removal.

Tamsalu V-plows (butterfly plows) are robust and high-performance attachments engineered for professional snow clearance in demanding Nordic environments. With wings that can be controlled independently via hydraulics, the V-plow offers unparalleled flexibility: it can push snow to the left or right, collect it in a “scoop” position, or clear wide areas as a straight blade. This makes it the ultimate tool for narrow forest paths, urban streets, and large industrial parking lots alike.

The plow’s specialized curved geometry is optimized for smooth snow rolling, which significantly reduces towing resistance and fuel consumption. Great emphasis has been placed on safety and durability – the equipment features a smart protection system consisting of rubber buffers and a safety valve connected to a hydraulic accumulator. This system dampens shocks if the blade strikes a hidden obstacle (such as a curb or manhole cover), protecting both the plow and the tractor. It is a durable and reliable choice for maintenance contractors who need equipment that delivers even in the deepest snow.

Proven Reliability

Certified Wear Steel

Standard Quick Couplers

Responsive Customer Support

Technical Features

Hydraulic Versatility

Wings are independently rotatable by +-30 degrees, allowing V-shape, scoop, or straight blade configurations to suit any environment.

Advanced Control

Wing management via an electromagnetic hydraulic distributor (compatible with both 12V and 24V electrical systems).

Dual Protection System

Spring-loaded rubber buffers allow the blade to tilt back up to ^{\circ}$ upon impact, while the hydraulic accumulator safety valve prevents sudden pressure spikes.

High-Grade Materials

Equipped as standard with HARDOX wear-resistant steel edges for clean results and exceptional service life.

Adjustable Setup

Includes adjustable support legs as standard; rubber edge kits are available as an alternative for sensitive surfaces.

V-Plows LS-V Series (2.8 m – 3.3 m).

Smart Snow Removal with Maximum Flexibility.

High-performance hydraulically controlled V-plows engineered for professional snow clearance on both roads and parking areas. The robust design and rubber-buffer safety system ensure long-term durability and secure operation.

Technical Specifications

Download the brochure

Model	Blade Width	Blade Height	Weight	Working Width max/min	Blade Rotation
V-Plow LS 2.8 V (for loaders, lifting frame, or front mount)	2,8 m	0,70 m	860 kg	Max: 2,8 m Min: 2,47 m	+/- 30°
V-Plow LS 2,8 V (Push frame)	2,8 m	0,70 m		Max: 2,8 m Min: 2,47 m	+/- 30°
V-Plow LS 3,3 V (for loaders, lifting frame, or front mount)	3,3 m	0,95 m	950 kg	Max: 3,3 m Min: 2,8 m	+/- 30°
V-Plow LS 3,3 V (Push frame)	3,3 m	0,95 m		Max: 3,3 m Min: 2,8 m	+/- 30°

Additional specifications:

The blades are hydraulically rotatable +/- 30°.
Control system via electromagnetic hydraulic distributor (12V / 24V).
Equipped with a blade protection valve connected to a hydro-accumulator.
Safety system with rubber buffers, allowing blade movement to revert back at 45°.
Optional rubber blades are available.
Includes adjustable support legs.
Hardox metal blades can be substituted with rubber blades for models LS2.7 to LS3.6.
