Tilting grading buckets

Hydraulically tiltable profile for precise surface treatment, road construction, and landscaping.

Precision Tilting Grading Buckets for Perfect Grading

Tamsalu tilting grading buckets are indispensable tools when the goal is a perfectly smooth surface and precise slopes. Equipped with a powerful hydraulic system and dual cylinders (on larger models), the bucket allows for smooth tilting up to 45 degrees in both directions. This makes grading slopes, smoothing ditch banks, and preparing road bases significantly faster, reducing the need for manual labor.

Our grading buckets are built with a low and wide profile, providing the operator with excellent visibility and stable control over the cutting edge. The reinforced spine and specially selected wear-resistant steel in the cutting edge ensure the bucket maintains its geometry and precision even after thousands of working hours in harsh conditions.

Proven Reliability
Certified Wear Steel
Standard Quick Couplers
Responsive Customer Support

Technical Features

Dual-Cylinder Tilting Mechanism
Ensures stable and powerful pressure at both ends of the blade, holding the bucket firmly at the selected angle even when pushing heavy soil.
Wear-Resistant Cutting Edge
Comes standard with an ultra-high-strength blade that resists abrasive wear and extends service intervals.
Protected Hydraulic System
Cylinders and hoses are positioned behind the bucket structure or under protective covers to prevent damage from falling debris or soil impact.

Tilting Grading Buckets

Master the Slopes

Designed for precision grading and landscaping, our tilting buckets offer 45° of hydraulic movement in both directions. Featuring a low-profile design for superior visibility and reinforced wear zones for long-lasting performance.

Technical Specifications

Machine class up to 5t.

Name Volume, L Machine weight Blade dimension, mm Weight, kg Cylinders
KP55HD-H2 55 1,5 – 2,5t. 12 x 100 x L830 75 2 (H)
KP75HD-H2 75 1,5 – 2,5t. 12 x 100 x L1040 80 2 (H)
KP90HD-H2 90 1,5 – 2,5t. 12 x 100 x L1000 90 2 (H)
KP125HD-H2 125 2,5 – 5t. 12 x 100 x L1000 125 2 (H)
KP150-H2 150 2,5 – 5t. 20 x 200 x L1080 180 2 (H)
KP175-H2 175 2,5 – 5t. 20 x 200 x L1080 210 2 (H)
KP190-H2 190 2,5 – 5t. 20 x 200 x L1080 225 2 (H)
KP220-H2 220 2,5 – 5t. 20 x 200 x L1080 240 2 (H)
KP240-H2 240 2,5 – 5t. 20 x 200 x L1080 260 2 (H)

Machine class from 8,5t.

Name Volume, L Machine weight Blade dimension, mm Weight, kg Cylinders
KR320-V1 320 5 – 10t. 20 x 200 x L1350 358 1 (V)
KP270-H2 270 5 – 10t. 16 x 150 x L1220 310 2 (H)
KP350-H2 350 5 – 10t. 20 x 200 x L1330 335 2 (H)
KP550-V1 550 13 – 20t. 30 x 270 x L1450 820 1 (V)
KP650-V1 650 13 – 20t. 30 x 270 x L1550 900 1 (V)
KR550-V1 550 13 – 20t. 30 x 270 x L1620 850 1 (V)
KP900-V1 900 13 – 20t. 30 x 270 x L1700 960 1 (V)
KP900-V2 900 13 – 20t. 30 x 270 x L1700 1004 2 (V)
KP950-H2 950 13 – 20t. 30 x 270 x L1750 1020 2 (H)
KP1100-V1 1100 13 – 20t. 30 x 270 x L1900 1175 1 (V)
KP1100-V2 1100 13 – 20t. 30 x 270 x L1900 1210 2 (H)
KP1100-V2 1100 20 – 25t. 30 x 270 x L1900 1280 2 (H)
KP1150-H2 1150 13 – 20t. 30 x 270 x L1950 1210 2 (H)
KP1150-H2 1150 20 – 25t. 30 x 270 x L1950 1300 2 (H)
KP1300-V2 1300 35t. 40 x 375 x L2100 1850 2 (V)

H – Horizontal cylinder | V – Vertical cylinder
